SpaceLogic, Schneider, KNX, Presence Sensor, [MTN6300-0019], 9m motion detection sensor with 360° degree detection, 2 digital inputs
SKU:
MTN6300-0019
click to copy
Product condition: New and original packaging. With 18 Months Warranty.
Original price was: €99,00.€76,44Current price is: €76,44.
+ Shipping
Bulk order possibility | Bulk discounts apply
Qty
1-4 pieces
5-9 pieces
10+
Price
Original price was: €99,00.€76,44Current price is: €76,44.
Original price was: €99,00.€76,44Current price is: €76,44.
Contact us
In stock
Bulk Pricing Valid
Your Negotiated Price: Contact Sales Team
Fast Turnaround Guarantee
We usually respond to quote requests within 2 hours during business hours
🔐 Secure Shopping and Payment
✅ Global Corporate Partner
Instant Stock and Delivery
✅ Secure Business Transactions
✅ Bulk Purchase Prices
✅ Global Corporate Partner
✅ Satisfaction Guarantee
Technical Data
Schneider MTN6300-0019 SpaceLogic KNX Presence Sensor offers 2-channel control with 360° detection angle and 9 m detection range. With two digital inputs and 1-2000 lux adjustable sensitivity, it is ideal for lighting and HVAC automation applications in commercial buildings.
Width
10.0 cm
Height
8.5 cm
Depth
10.0 cm
Product Identity
MTN6300-0019
Manufacturer
Schneider Electric
Product Description
SpaceLogic KNX Motion Sensor: Advanced Motion Detection for Smart Building Management
Benefits:
- Optimum Lighting Control: It offers energy saving and user comfort by providing automatic light control according to motion and ambient brightness.
- Enhanced Security: Triggers additional functions linked to motion detection, deterring potential burglars and creating a safer environment.
- Flexible Configuration: Adjustable sensitivity with automatic, semi-automatic and test modes ensures precise adaptation to your needs.
- Expandable Detection: It is ideal for large spaces by expanding the detection area by connecting secondary sensors to the main sensor.
- Easy Integration: It connects directly to the KNX system and works seamlessly with other KNX devices.
Features:
- Detection Range: 360° angle, detection capacity up to 9 meters.
- Digital Inputs: Option to connect two lighting controls or switches for dimmable light adjustment.
- Adjustable Sensitivity: Optimizes performance by fine-tuning detection sensitivity.
- Ambient Brightness Adjustment: Customize light level triggers.
- Time Adjustment: Adjust the on and off delay times of the lights.
- Navigation Test Mode: Easily configure and verify detection coverage.
- Red LED Indicator: Visually confirms motion detection.
- Assembly: Ceiling recessed installation, ideal height 2.5 meters.
- Technical Specifications:
- KNX bus voltage and current: 24V, 10mA
- Dimensions: (Width) 99.2mm x (Height) 99.2mm x (Depth) 74.1mm
- Material: Plastic
- Color: White (RAL 9003)
- Protection Class: IP20
Commercial Practices:
The SpaceLogic KNX Motion Sensor DI is ideal for a variety of commercial buildings:
- Offices Automates lighting, creating an energy efficient workspace.
- Hotels Increases guest comfort and safety with automatic light control in hallways and washbasins.
- Retail Spaces: Enhances the customer experience with dynamic light settings based on motion.
- Warehouses: Provides light optimization and motion-based intrusion detection.
Note
- Please refer to the manufacturer's documentation for technical details and KNX system information.
- This product description is for informational purposes only and may be incomplete.
Increase the intelligence and efficiency of your building with the SpaceLogic KNX Motion Sensor. Enjoy convenient lighting control, increased security and a more comfortable environment for everyone.
Schneider Electric MTN6300-0019 SpaceLogic KNX Presence Sensor is a 2-channel presence detector designed for lighting and HVAC control in commercial building automation projects. The device communicates via the KNX bus protocol and the supply voltage is supplied directly from the KNX line; bus current is 10 mA.
The sensor has a 360° detection angle and offers a 9 m motion detection range and 9 m presence detection range. The detection radius is 4.5 m. Photosensitivity can be adjusted between 1 and 2000 lux and duration can be set. The device is capable of detecting even small movements within the detection area.
Two digital inputs allow direct connection of external devices such as conventional switches. The detector can be configured in three different operating modes: automatic mode, semi-automatic mode and test mode. It can be used alone or in combination with the primary-secondary configuration.
Its physical dimensions are 99.2 mm (W) x 99.2 mm (H) x 74.1 mm (D) with a recessed depth of 60.8 mm. It is designed for ceiling installation and the recommended installation height is 2.5 m. Made of matt white (RAL 9003) plastic material. IP20 degree of protection.
The device is KNX certified and is suitable for lighting, heating, air conditioning and shading control in small, medium and large commercial buildings. Package weight is 345 g and 18 months warranty.
Documents
User manual (PDF)
MTN6300-0019 User manual
Catalog (PDF)
Schneider Electric Catalog
Software - Data Library - ETS (ZIP)
MTN6300-0019ETS Data
SSS
What is the detection area and angle of the MTN6300-0019 sensor?
The sensor has a 360° detection angle. The motion detection range is 9 m, the presence detection range is 9 m and the detection radius is 4.5 m.
What is the supply voltage and bus current of the device?
The device is powered directly from the KNX bus and the bus current is 10 mA.
In which range can the light sensitivity be adjusted?
Detection brightness can be adjusted between 1 and 2000 lux. Duration can also be adjusted.
What are the mounting conditions and dimensions?
Designed for ceiling installation, recommended installation height is 2.5 m. Its dimensions are 99.2 x 99.2 x 74.1 mm with a recessed depth of 60.8 mm. IP20 protection rating.
Which operating modes does the device support and how many channels does it control?
The detector can operate in three modes: automatic mode, semi-automatic mode and test mode. It controls 2 channels and supports external device connection with 2 digital inputs. It can be used alone or in primary-secondary configuration.
